Votre traceur HP DESIGNJET 1050C, 1050C+, 1055CM est en panne ?

Notre technicien intervient sur site pour le dépanner.

'HP DESIGNJET 1050C, 1050C+, 1055CM'

Diagnostic gratuit par téléphone

Accueil personnalisé sans serveur vocal par notre technicien à Lyon.
Nos techniciens expérimentés sont à votre écoute pour faire le diagnostic de la panne que vous rencontrez sur votre traceur HP Designjet.

Devis en 2 heures, dépannage en 48 heures

• Notre technicien réalise immédiatement votre diagnostic par téléphone.
• Notre devis de réparation vous est adressé sous 2 heures.
• Notre procédure d’ouverture de compte est réduite au maximum.
Ainsi, en fonction de votre disponibilité, notre technicien SAV interviendra sous 48 heures à réception du devis accepté.

Nous vous dépannons à Lyon et en Rhône-Alpes

• Nous intervenons toujours en direct et sans sous-traitant.
• Afin de garantir à nos clients des interventions en 48 heures, nous intervenons uniquement en Rhône Alpes :
• Rhône, Ain, Isère, Savoie, Haute-Savoie, Loire, Drôme, Saône-et-Loire.
• Lyon et Grand Lyon, Villeurbanne Grenoble, Chambéry, Annecy, Bourg en Bresse, Valence, Saint Etienne, Macon, Châlon-sur-Saône.

Nous prenons en charge toutes les pannes

Nos techniciens sont méticuleux et prennent en charge tous les problèmes :
Pièces d’usure, codes erreur, pannes électroniques, problèmes de qualité d’impression, paramétrages et configuration informatique...

Nous avons toutes les pièces en stock

Afin d’être certain de terminer votre réparation au premier dépannage, nos techniciens SAV se déplacent avec toutes les pièces nécessaires, possibles et imaginables : Courroie, trailing cable, strip encoder, station service, chariot, cutter, star wheels motor, carte formatter, bloc d’alimentation, spindle, mais aussi cartouches, têtes d’impressions...
Notre stock et nos compétences nous permettent de résoudre la plupart des pannes dès le premier dépannage.

Nos tarifs sont raisonnables

En général, nos dépannages sont facturés au temps passé, 85 € ht de l’heure.
Les frais de déplacement sont facturés en fonction de votre éloignement, 85 € ht si vous êtes sur Lyon.
Nous remplaçons uniquement les pièces nécessaires.
• Si votre traceur nécessite une maintenance de routine (remplacement de courroie), nous remplacerons uniquement ces pièces.
• Si votre traceur a des pannes multiples, nous pourrons vous proposer un forfait ou un échange standard.
• Si une réparation n’est pas économiquement rentable, ou si le dépannage ressemble à de l’acharnement thérapeutique, nous vous le signalerons quitte à ce que vous annuliez l’intervention.

Indiquez-nous le code erreur ou le problème rencontré
pour obtenir un diagnostic ou un devis de réparation.

Codes erreur les plus fréquents - Traceur HP DESIGNJET 1050C, 1050C+, 1055CM

Code Erreur 86:01 ou Vérifier chemin des têtes d'impression ou Vérifier chemin papier

Tableau de tous les codes erreurs - Traceur HP DESIGNJET 1050C, 1050C+, 1055CM

0000D8 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

136

- code :

0000D8

- description :

External Library Error.

- remede :

Power the Printer OFF and ON again to see if the System Error disappears. If the Error Code reappears, then report the error to the HP response Center or the nearest HP Support Office, stating the following information.

010020 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

137

- code :

010020

- description :

Firmware DIMM Test failure.

- remede :

•Switch the Power OFF from the back of the Printer and disconnect the Power cord. Reseat the Firmware DIMM, reconnect the power cord and power On the Printer. •If the Error Code appears again, switch the Power OFF from the back of the Printer, disconnect the power cord and Replace the Firmware DIMM. Reconnect the power cord and power On the Printer and check if the Error Code has been resolved. •If the System Error continues, replace the Electronics Module.

010021 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

138

- code :

010021

- description :

Memory DRAM DIMM Test failure.

- remede :

•Switch the Power OFF from the back of the Printer and disconnect the Power cord. Reseat the DRAM DIMMs (Memory Modules), reconnect the power cord and power On the Printer. •If the Error Code appears again, switch the Power OFF, disconnect the power cord and Replace the Flash DIMMs (Memory Modules). Reconnect the power cord and power On the Printer and check if the Error Code has been resolved. •If the Error Code continues, replace the Electronics Module.

010023 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

139

- code :

010023

- description :

EEROM Test failure.

- remede :

•Clear the EEROM and turn the Printer OFF and ON again from the back of the Printer. If after clearing the EEROM, the Error Code disappears, make sure you perform the Calibrations Backup . •If the Error Code continues, replace the Electronics Module.

01002D HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

140

- code :

01002D

- description :

The Main PCA cannot communicate with the Carriage.

- remede :

Perform the Electronic Systems Test.

010040 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

141

- code :

010040

- description :

Error in Paper-axis Encoder quadrature.

- remede :

•Check that the Paper-Axis Motor cable is NOT broken or damaged. •Check that the Paper-Axis Motor cable is correctly connected.• Replace the Paper-Axis Motor .• If the Error Code continues, replace the Electronics Module

010041 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

142

- code :

010041

- description :

Error in Scan-axis Encoder quadrature.

- remede :

• Check that the Encoder Strip is NOT broken or damaged.• Replace the Encoder Strip .• Replace the Carriage Assembly .• If the Error Code continues, replace the Electronics Module

010042 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

143

- code :

010042

- description :

Error in Service Station-axis Encoder quadrature.

- remede :

• Check that the Service Station Encoder-Cable is NOT broken or damaged.• Check that the Service Station Encoder-Cable is correctly connected.• Replace the Service Station .• If the Error Code continues, replace the Electronics Module

010050 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

144

- code :

010050

- description :

PostScript Processing Error.

- remede :

• Model and Serial Number of the printer.• Which firmware revision the printer is using (See Note below). Check firmware in Utilities / Statistics / Code rev.• The complete error number (See Note below).• The Service Configuration Print.• The Current configuration sheet.• Which software application the customer is using (name, version, etc.).

01009X HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

145

- code :

01009X

- description :

Error in Paper-axis Motor Encoder

- remede :

• Check that the Paper-Axis Motor cable is NOT broken or damaged.• Check that the Paper-Axis Motor cable is correctly connected.• Replace the Paper-Axis Motor.• If the Error Code continues, replace the Electronics Module

02xxxx HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

146

- code :

02xxxx

- description :

PostScript/Firmware Error.

- remede :

Power the Printer OFF and ON again to see if the System Error disappears. If the Error Code reappears, then report the error to the HP response Center or the nearest HP Support Office, stating the following information.

048xxx HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

147

- code :

048xxx

- description :

The EIO card is from a third party vendor and may not be fully compliant with the IIO Protocol specification 2.0 OR the EIO Card firmware is not updated.

- remede :

• Check with the third party vendor. If the EIO card is not compliant with the IIO Protocol specification 2. then you must install a new EIO card which is compliant.• Update the EIO Card firmware.

04Cxxx HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

148

- code :

04Cxxx

- description :

EIO Accessories (EIO Card/Hard Disk Drive) Error.

- remede :

• Press ENTER and switch the printer OFF. Remove the Hard Disk Drive (if installed) and make sure that the EIO card is installed correctly by pushing it firmly inwards and checking that the two installation screws are completely tightened. Switch the printer ON again. If this error code continues to appear then replace the EIO card.• If this Error Code disappeared after removing the Hard Disk Drive, then switch the Printer OFF and reinstall the Hard Disk Drive, making sure that the two instal

060301 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

149

- code :

060301

- description :

One of the Printheads has an Internal Electrical Problem.

- remede :

• Remove all the Printheads and clean the flex contacts on the Printheads and in the Carriage Assembly (Refer to Chapter 2).• Perform the Electronic Systems Test.• Make sure that the Trailing Cable is connected correctly.• Replace the Trailing Cable.• Replace the Carriage Assembly.• If the error code continues, replace the Electronics Module

060305 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

150

- code :

060305

- description :

Thermal Shutdown error (one of the Printheads has gone above the maximum Temperature). 00000000 - Cyan Printhead Failed. 00000001 - Magenta Printhead Failed. 00000002 - Yellow Printhead Failed. 00000003 - Black Printhead Failed.

- remede :

• Replace the failing Printhead.• If the problem remains after replacing the failing Printhead then check if the customer is using a 3rd Party RIP. If a 3rd Party RIP is being used, check the Print Settings in the RIP or try printing one of the Internal Demo Prints to see if the problem is solved without the RIP.

060309 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

151

- code :

060309

- description :

Problem with setting the Voltage of the Printheads.

- remede :

• Remove ALL the Printheads and clean the flex contacts on the Printheads and in the Carriage Assembly (Refer to Chapter 2).• Perform the Electronic Systems Test.• Replace ALL the Printheads.• Replace the Trailing Cable.• Replace the Carriage Assembly.• If the Error Code continues, replace the Electronics Module

06030A HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

152

- code :

06030A

- description :

Error in finding the Mark Encoder.

- remede :

• Clean the Mark Encoder if necessary (use the Overdrive Cleaning Utility to position the Mark Encoder).• Clean the Line Sensor (located on the Carriage Assembly).• Perform the Line Sensor Calibration.• Perform the Mark Encoder Calibration.• Replace the Trailing Cable.• Replace the Carriage Assembly.• If the Error Code continues, replace the Electronics Module

06030B HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

153

- code :

06030B

- description :

The Ambient Temperature measured is out of the normal range.

- remede :

• Make sure that the Ambient temperature is within the allowed range (between and 55 Degrees Centigrade).• Replace the Electronics Module.

070100 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

154

- code :

070100

- description :

Firmware Error.

- remede :

• Model and Serial Number of the printer.• Which firmware revision the printer is using (See Note below). Check firmware in Utilities / Statistics / Code rev.• The complete error number (See Note below).• The Service Configuration Print.• The Current configuration sheet.• Which software application the customer is using (name, version, etc.).

080001 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

155

- code :

080001

- description :

PostScript Error.

- remede :

Power the Printer OFF and ON again to see if the System Error disappears. If the Error Code reappears, then report the error to the HP response Center or the nearest HP Support Office, stating the following information.

09xxxx HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

156

- code :

09xxxx

- description :

EIO Accessories (EIO Card/Hard Disk Drive) Error.

- remede :

• Switch the Printer OFF and ON again and wait for the initialization.• If the Error code continues to appear, switch the Printer OFF. Remove the EIO Card (if installed) and make sure that the Hard Disk Drive is installed correctly by pushing it firmly inwards and checking that the two installation screws are completely tightened. Switch the Printer ON again. If the error codes 9Axxx or 9Bxxx appear then replace the Hard Disk Drive.• If the Error Code disappeared after removing the EIO Card

0A0000 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

157

- code :

0A0000

- description :

The Air Pressure is below the minimum requirement.

- remede :

n Check all the cables of the APS and make sure they are correctly connected and are NOT damaged. n Check all the tubes of the APS and Tubes System and make sure they are correctly connected and are NOT pinched or damaged. n Check that the Air Tube from the APS is correctly connected to the Tubes System. n Faulty APS Sensor, APS Valve or APS Pump. Replace the complete APS. n Replace ONE Ink Cartridge at a time, checking if the error code disappears.

0A0010 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

158

- code :

0A0010

- description :

Problem in Pressurizing the Air System.

- remede :

• Replace ONE Ink Cartridge at a time, checking if the error code disappears.• Check all the cables of the APS and make sure they are correctly connected and are NOT damaged.• Check all the tubes of the APS and Tubes System and make sure they are correctly connected and are NOT pinched or damaged.• Faulty APS Sensor, APS Valve or APS Pump. Replace the complete APS.

0A0020 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

159

- code :

0A0020

- description :

Error in Calibrating the APS Sensor.

- remede :

• Check all the cables of the APS and make sure they are correctly connected and are NOT damaged.• Check all the tubes of the APS and Tubes System and make sure they are correctly connected and are NOT pinched or damaged.• Faulty APS Sensor or APS Valve. Replace the complete APS

0A0030 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

160

- code :

0A0030

- description :

Problem in Depressurizing Air System.

- remede :

• Check the APS for any signs of Ink. Also inspect ALL Ink Cartridges for any signs of leaking (the bottom valve of the Ink Cartridge will contain ink).• If there is Ink Leakage, replace ALL Ink Cartridges, the APS (

0A0040 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

161

- code :

0A0040

- description :

Ink Tubes Initialization Failure Due to Low Air Pressure.

- remede :

• Check all the cables of the APS and make sure they are correctly connected and are NOT damaged.• Check all the tubes of the APS and Tubes System and make sure they are correctly connected and are NOT pinched or damaged.• Replace ONE Ink Cartridge at a time, checking if the error code disappears.• Faulty APS Sensor or APS Pump. Replace the complete APS

0A0050 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

162

- code :

0A0050

- description :

The Printer has detected a leak in the Tubes System before the life of the System.

- remede :

• The leak detector could have been triggered due to condensation in the Printer. Power OFF the Printer and allow the Printer to dry for 15 minutes. Power ON the Printer and check if the error code has disappeared.• If the Error Code reappears, replace the complete Tubes System (SRK).

0A0060 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

163

- code :

0A0060

- description :

The Printer has detected a leak in the Tubes System after the life of the System.

- remede :

• The leak detector could have been triggered due to condensation in the Printer. Power OFF the Printer and allow the Printer to dry for 15 minutes. Power ON the Printer and check if the error code has disappeared.• If the error code reappears, replace the complete Tubes System (SRK).

0A0070 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

164

- code :

0A0070

- description :

The Backup EEROM contents stored in the Tubes System are not consistent with the ones required by the firmware.

- remede :

• Perform the Calibrations Backup.

0B0000 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

165

- code :

0B0000

- description :

Bad Ambient Temperature measured.

- remede :

• Make sure that the Ambient temperature is within the allowed range (between and 55 Degrees Centigrade).• Replace the Electronics Module.

0B0001 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

166

- code :

0B0001

- description :

Bad Humidity read.

- remede :

Replace the Electronics Module

0B0002 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

167

- code :

0B0002

- description :

Bad IDS pressure read.

- remede :

• Check that the cable from the Ink Supply Station (ISS) PCA to the Ink Supply Station is correctly connected.• Check that the Air Pressurization System Sensor Cable is correctly connected and is NOT damaged.• Check all the tubes of the APS and make sure they are NOT pinched or damaged.• Faulty APS Sensor. Replace the complete APS.• If the error code continues, replace the Electronics Module

0B0003 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

168

- code :

0B0003

- description :

ADC0 Internal channels check Failure.

- remede :

Replace the Electronics Module

0B0004 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

169

- code :

0B0004

- description :

Unable to detect Pump.

- remede :

• Check that the cable from the Ink Supply Station (ISS) PCA to the Ink Supply Station is correctly connected.• Faulty APS Pump. Replace the complete APS.• If the error code continues, replace the Electronics Module

0B0005 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

170

- code :

0B0005

- description :

Unable to detect Valve.

- remede :

• Check that the cable from the Ink Supply Station (ISS) PCA to the Ink Supply Station is correctly connected.• Faulty APS Valve. Replace the complete APS.• If the error code continues, replace the Electronics Module

0B0006 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

171

- code :

0B0006

- description :

The Trailing Cable has been incorrectly connected OR the fuse in the Electronics Module has been burned.

- remede :

Turn the Printer OFF and disconnect the trailing cable. Check that the ends of the Trailing Cable are flat and are not damaged or bent. Reconnect the Trailing Cable correctly, making sure it is pushed in firmly (Refer to the instructions on Page 8-39). Power ON the Printer and check if the Error Code disappears. If the Error Code continues, replace the Electronics Module (Refer to the instructions on Page 8-25), making sure you take care when you reconnect the Trailing Cable.

0B0007 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

172

- code :

0B0007

- description :

Unable to detect Vacuum Fan.

- remede :

• Make sure that the Vacuum Fan is connected correctly to the Electronics Module.• Turn the Printer OFF and disconnect the Vacuum Fan from the Electronics Module. Connect a New Vacuum Fan to the Electronics Module and power ON the Printer. If the New Vacuum Fan functions correctly without any Error Codes then remove the Old Vacuum Fan from the Printer and install the New one.• If the New Vacuum Fan does not function correctly either, then replace the Electronics Module.

0B0008 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

173

- code :

0B0008

- description :

Unable to detect Cooling Fan.

- remede :

Replace the Electronics Module

0B0009 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

174

- code :

0B0009

- description :

Unable to detect Aerosol Fan (Included on the Right Cover).

- remede :

• Make sure that the Aerosol Fan is connected correctly to the Electronics Module.• Turn the Printer OFF and disconnect the Aerosol Fan from the Electronics Module. Connect a New Aerosol Fan (comes with the new Right Cover) to the Electronics Module and power ON the Printer. If the New Aerosol Fan functions correctly without any Error Codes then remove the Old Aerosol Fan from the Printer and install the New one.• If the New Aerosol Fan does not function correctly either, then replace the Ele

0B000A HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

175

- code :

0B000A

- description :

Primer Shutdown Error.

- remede :

• Check that the Primer Stepper-Motor Cable is NOT broken or damaged and that the Primer arm moves freely from side to side.• Replace the Service Station.• If the Error Code continues, replace the Electronics Module

0B000B HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

176

- code :

0B000B

- description :

Pump or Pressure Sensor not working.

- remede :

• Check that the cable from the Ink Supply Station (ISS) PCA to the Ink Supply Station is correctly connected.• Check that the Air Pressurization System Sensor Cable is correctly connected and is NOT damaged.• Check all the tubes of the APS and make sure they are NOT pinched or damaged.• Faulty APS Sensor, APS Valve or APS Motor. Replace the complete APS.• If the error code continues, replace the Electronics Module

0B000C HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

177

- code :

0B000C

- description :

Serial Device ADC test failure

- remede :

Replace the Electronics Module

0B000D HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

178

- code :

0B000D

- description :

24 V source test failure.

- remede :

Replace the Electronics Module

0C0030 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

179

- code :

0C0030

- description :

Bad Drop Detector.

- remede :

• Check that the Drop Detector Cable is NOT broken or damaged.• Check that the Drop Detector cable is correctly connected to the Service Station Cable.• Remove the Drop Detector and make sure that there are no obstacles inside which are blocking the sensor.• Replace the Drop Detector Assembly.• If the Error Code continues, replace the Electronics Module

0C0032 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

180

- code :

0C0032

- description :

Drop Detector not Calibrated for all Printheads.

- remede :

• Perform the Service Station Calibration.• Replace the Drop Detector Assembly.• If the Error Code continues, replace the Electronics Module

0C1000 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

181

- code :

0C1000

- description :

Primer not Calibrated.

- remede :

• Perform the Service Station Calibration.• Make sure that the Primer Arm is not damaged. If the Primer Arm is damaged, replace the Service Station.• Replace the Electronics Module.

0C1001 HP DESIGNJET 1050C, 1050C+, 1055CM

- id :

182

- code :

0C1001

- description :

Primer Shutdown Error.

- remede :

• Check that the Primer Stepper-Motor Cable is NOT broken or damaged and that the Primer arm moves freely from side to side.• Replace the Service Station.• If the Error Code continues, replace the Electronics Module
